Dlux
Dlux 92mm (Short) Shocks with Traxxas Rebuild Kits (4)
SKU: DLX-58092-BLKu
Only 1 product left
Color: Black
Pickup available at Key City Hobby
Usually ready in 1 hour
Dlux 92mm (Short) Shocks with Traxxas Rebuild Kits (4)
Based on the original Dravtech design, the Dlux Big Bore shocks have come a long way.
**Sold in sets of 4**
Please understand that the anodizing varies from batch to batch, so the color of the shocks might be slightly different from the pictures shown or previous batches that DLUX has sold.
Extended length (eye to eye): 92mm approx. (without optional internal spacer)
Collapsed length (eye to eye): 71mm approx. (without optional internal spacer)
Shock Travel: 21mm approx. (without optional internal spacer)
Product Details:
- The best quality shocks you can buy in this price range.
- Internal bladder to keep the oil separate from the air. This provides a quicker, more precise and consistent damping response. This is equivalent to the internal floating piston found in high end Bilstein, Fox, or King monotube shocks in the automotive world.
- High quality double o-ring seal, making them leak free for years (when correct oil filling procedure is used).
- 4 hole piston for the maximum damping range - depending on which oil you choose, they are easily soft enough for a lightweight mini class or stiff enough for a heavy trail truck.
- Exceptionally smooth!
- Compact to solve fitment issues associated with larger shocks.
- 2 spring rates included (soft springs installed, medium springs included). Purchase additional spring rates here.
- Preload o-rings included for precise ride height tuning.
Internal spacers are available here to shorten extended length and travel. Can also be installed externally to shorten collapsed length and travel.
Click here to find compact offset shock caps to shorten extended and collapsed lengths without affecting travel.
Included with your shocks:
(4) shock absorbers, fully assembled, just add oil (not included).
(4) soft springs.
(4) medium springs.
(12) preload O-Rings for ride height adjustment, pre-installed, remove as needed.
**No oil installed or included**
You will most likely need some small snap ring pliers to assemble these shocks. Channel lock part #927 or even smaller #926 are great, Imperial part #IR-250H are also known good pliers.Â
