AGF-RC

AGF-RC 1.4KG Micro Programmable Coreless Digital RC Servo for Mini Car

SKU: A11CLS V3

Only 9 products left

Sale price $54.99

Pickup available at Key City Hobby

Usually ready in 1 hour


  • (1) A11CLS V3 Servo
  • (4) 25T Plastic Horn
  • (2) Mounting Screw
  • (1) Servo Horn Screw


AGF-RC 1.4KG Micro Programmable Coreless Digital RC Servo for Mini Car

AGFrc A11CLS V3 Mini Z Scale Digital Programmable Servo. The use of high quality coreless motor, high accuracy titanium gear and 2 ball bearings, so that it working stable and smooth. It has programmable function which support to adjust the servo parameter as required.

Spec Sheet

Latest Product Firmware

Product CAD File

  • Full CNC Aluminum Case
  • High Quality Coreless Motor
  • High Precision Metal Gear
  • Programmable Digital Circuit for Parameter Adjustment
  • Design for mini z cars MRZ, 1/18, 1/24, 1/27, Scale Cars such as GL Racing GLD, GLA V2.1, GLR, GLF-1, GLR GT
  • Voltage Range: 4.8V ~ 6.0V
  • Gear Material: Titanium
  • Pulse Width: 500 ~ 2500 µSec
  • Dimension: 20*11.3*21 mm
  • Bearing: 2BB
  • Net Weight: 11 g
  • Case Material: AL6061T6
  • Wire: JR / JST1.5 80mm / 30AWG
  • Direction: CCW
  • Temperature: -15°C ~ +70°C
  • Refresh Rate: 1520 µS / 333Hz
  • Motor Type: Coreless
  • Dead Band: 3 µSec
  • Gear Spline: 25T-ɸ4.94 mm
  • Travel Angle: 180 ± 10°
  • Wire Color: ⚫️ 🔴 ⚪️
  • 4.8 V Operating Speed | Stall Torque: 0.065 sec/60° | 1.2 kg·cm (17 oz·in)
  • 6.0 V Operating Speed | Stall Torque: 0.050 sec/60° | 1.4 kg·cm (19 oz·in)
